Endo ATB-2 Air Tool Spring Balancer Capacity 6.6-11.0 lbs

Manufacturer: ENDO
SKU: XA-ATB-2
Manufacturer part number: XA-ATB-2
Lead Time (subject to change, call to verify): typically ships in 5-7 business days
*
$462.63
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Documents, Drawings, and Manuals
Product Specifications
Attribute nameAttribute value
Features
  • Capacity Range: 6.6 to 11.0 lbs. (3.3 to 5.0 kg)
  • Max Pressure Rating: 145 psi (1.0 MPa / 10 bar)
  • Air Hose Travel: 4.27 ft. (1.3 m)
  • Air Hose Diameter: 1/4 in. ID (6.35 mm)
  • Air Inlet: 1/4 in. NPT (6.35 mm)
  • Unit Weight: 3.8 lbs. (1.73 kg)
  • Width: 7.5 in. (190 mm)
  • Depth: 3.3 in. (83.8 mm)
  • Length (hook to fitting): 10.0 to 61.3 in. (254 to 1557 mm)
  • Color: Safety Yellow
  • Air Hose Material: Braided Polyurethane
  • Top Hook: Steel swivel hook with safety latch.
  • Secondary Support: Includes top support eyelet to accommodate a safety chain.
  • High impact cast ABS plastic housing.
  • Easy and precise ratchet system spring adjustment.
  • Zero-Gravity tool holding with no drifting or strain.
  • Tapered drum, quality springs, and ball bearings provide smooth cable travel throughout the stroke.
  • CE mark NOT available (European Conformity)
  • Ratchet Spring Tension Adjustment:
    • Insert allen wrench in back of unit and turn clockwise to increase tension and counterclockwise to decrease tension (factory preset to the midrange of the rated capacity).
    • Watch Video Here
  • Choosing the Right Spring Balancer:
    • Size the balancer to carry the total weight of the tool and all accessories to be balanced.
    • Use the upper end of the capacity range of the balancer when possible. For example, if the total tool weight is 10.5 lbs, a balancer with a capacity range of 5.5-11.0 lbs would be a better choice than one with a range of 9.9-19.8 lbs.
    • Choose the cable travel length that best suits your application.
  • Note: This model does not have a fall arrest system to prevent the tool/load from dropping in the unlikely event that the spring breaks.
Warranty18-Month Manufacturer's Warranty. (Manufacturer's warranty does not include on-site repairs. Items will need to be shipped with pre-paid freight to EP's repair facility.)
Country of OriginJapan
