Gorbel Free Standing Tool Balancer Jib Crane, 50 lbs, Ht. 10 ft, Span 8 ft

Manufacturer: Gorbel
SKU: TSJ50-FS-50-10-8
Manufacturer part number: TSJ50-FS-50-10-8
Lead Time (subject to change, call to verify): typically ships in 10-13 business days
*
*
*
$1,953.72
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options
Product Specifications
Attribute nameAttribute value
Features
  • Model: TSJ50-FS-50-10-8
  • Capacity: 50 lbs.
  • Span: 8 ft.
  • Height Under Boom (HUB): 10 ft.
  • Overall Height (Crane Only): 11.22 ft.
  • Mast Pipe Size: 4 in.
  • Enclosed Track Series: 250
  • Overturning Moment: 709.3 lbs-ft
  • Axial Load: 233.49 lbs.
  • Anchor Bolt Load: 650.93 lbs.
  • Anchor Bolt Size: 1/2 in. dia. (4 EA. REQ. - NOT INCLUDED WITH JIB CRANE)
  • Coverage: 180° Semi-Circular Rotation
  • Shipping Weight (Overall Weight): 256 lbs.
  • Lightweight tie rod style ensures easy movement and high performance without giving you more crane than you need for low capacity applications.
  • Designed to be smaller, lighter, and more cost effective for applications with suspended tooling or light duty lifting.
  • Simple 4 bolt installation allows for easy adjustment of the height under boom.
  • Slim 4 inch square mast allows for foundationless installation in small areas where floor space may be limited, such as between machines.
  • All Gorbel Jib Cranes have a design factor of 15% of the allowable capacity for hoist weight and 25% of the allowable capacity for impact.
  • Foundationless models are mounted to a 6 inch reinforced floor that require:
    • Centered placement on a square area that is free from cracks, seams, and walls.
    • Chemical anchor bolts that can withstand a minimum of 283.84 pounds of pull out force.
    • Concrete pressure of 3,000 psi that contains wire mesh reinforcement.
Warranty10-Year Manufacturer's Warranty. (Manufacturer's warranty does not include on-site repairs. Items will need to be shipped with pre-paid freight to EP's repair facility.)
Country of OriginMade in the USA
